5.98 inch tft display module 1080*1920 resolution, 39pins MIPI interface, 2000 C/D,

Place of Origin China
Brand Name HuaXin
Certification ISO14001/ISO9001/IATF16949
Model Number ESHX060FHD40PP
Delivery Time 6~8weeks

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Sub Pixel Size 0.2025x 0.2025(mm) Product Applications Instruments, Meters
Power Supply LCD Module Surface Hard Coating, Antireflection
Size 5.98 Brightness 2000c/d
Backlight 1 White LED Resolution 1080X1920 Pixels
Leave a Message
Product Description

Product Description:

The Sunlight Readable TFT product is a touch screen LCD monitor that is perfect for use in a variety of applications. It is compatible with a 3.5 TFT LCD shield and a 2.4 inch TFT LCD display, making it easy to integrate into your existing systems and devices.

In addition to its superior visibility, this product also boasts excellent power efficiency. It requires a power supply of 2.8/3.3 (Typ.)(VCC/VDD1/VDD2), ensuring that it is both cost-effective and environmentally friendly. This makes it a great choice for businesses and organizations looking to reduce their energy consumption.

Overall, the Sunlight Readable TFT product is an excellent choice for anyone looking for a high-quality touch screen LCD monitor that is designed to be used in outdoor environments. Its superior visibility, power efficiency, and compatibility with a range of devices make it a versatile and practical choice for businesses and individuals alike.



Features:

  • Product Name: Sunlight Readable TFT
  • Backlight: 1 White LED
  • Viewport Window Size: 5.0 Inch
  • Model: HN-8064
  • Pixel Format: 1080xRGB×1920 [QVGA] 113PPI
  • Driving Method: Dot
  • Features: Automotive TFT Displays, lcd panel, tft display


Technical Parameters:

Part No:
ESHX060FHD40PP
unit
Size 尺寸 5.98 inches​ ​
Resolution 分辨率 1080*1920
Active Area 显示区域 74.52*132.48 mm
Outline dimension 外观尺寸 76.52*138.88*3.2 mm
Color Depth 颜色 16.7 M/216K colors
Display Mode 显示模式 Normally black Transmissive
Surface treatment 表面处理 AG
Interface 接口 MIPI 39PIN
View Angle 可视角度 80/80/80/80
Brightness 亮度 Min1000/TYP2000 Nits
Operating temperature 工作温度 -20 ... +70 °C
Storage temperature 储存温度 -30 ... +80 °C
Contrast ratio 对比度 Min800/Typ1000

This Industrial TFT Display is perfect for custom TFT LCD displays in instruments, meters, and advertising displays.



Applications:

With its IPS TFT LCD technology, the Sunlight Readable TFT LCD offers a color depth of 262K, delivering vivid and vibrant colors. It is also equipped with a 16:9 display ratio, making it ideal for displaying images and videos in widescreen format.

The Sunlight Readable TFT LCD is a type of A-Si TFT-LCD display, which means that it is made using an amorphous silicon thin-film transistor technology. This makes it highly efficient in terms of power consumption, ensuring that it can be used for extended periods without draining the battery excessively.

The backlight of the Sunlight Readable TFT LCD is a single White LED, which provides a uniform brightness across the entire display. This makes it easier to read information even in dimly lit environments.

The driving method of the Sunlight Readable TFT LCD is dot-driven, which means that each pixel is individually controlled. This allows for precise image placement and accurate color reproduction.

The Sunlight Readable TFT LCD is suitable for a wide range of applications. It can be used in outdoor digital signage, where it can withstand the harsh weather conditions and still provide a clear and readable display. It can also be used in industrial automation, where it can be used to display important information such as equipment performance data and production statistics. In addition, it can be used in transportation systems, such as on-board displays in trains and buses, or in aviation systems, such as cockpit displays.

The Sunlight Readable TFT LCD is a versatile and reliable display that offers high visibility and clarity in even the most challenging environments.



Customization:

With our Product Customization Services, you can tailor this display to fit your specific needs. Whether you require a specific size or aspect ratio, or need to modify the backlight or surface to enhance the visibility of your Colored Outdoor Spotlights, HuaXin can work with you to create a solution that meets your requirements. Contact us to learn more about our customization services.



Support and Services:

The Sunlight Readable TFT product technical support and services include:

- Product installation guidance

- Troubleshooting assistance for technical issues

- Warranty support and product repair services

- Product customization services

- Technical training and resources for our customers
