0.69 Inch PMOLED display module ,96x16 Resolution,IIC interface, driving ICSSD1306

PMOLED Display
May 16, 2023
Category Connection: PMOLED Display
Chat Now Contact Us
Tags:
#PMOLED Display #yellow oled display #oled screen
Brief: Discover the ESHX9616TSWCG02, a 0.69-inch PMOLED display module with 96x16 resolution, IIC interface, and SSD1306 driving IC. Perfect for wearable devices, car dashboards, and more, this module offers high contrast, vibrant colors, and power efficiency.
Related Product Features:
  • 0.69-inch PMOLED display module with 96x16 resolution for crisp and clear visuals.
  • 14-pin IIC interface for easy connectivity and integration.
  • Driving IC SSD1306 ensures reliable performance and compatibility.
  • Operating temperature range of -40°C to 85°C for versatile use.
  • High contrast and vibrant colors without the need for a backlight.
  • Compact module size of 26.3x8x1.2mm, ideal for space-constrained applications.
  • Suitable for wearable devices, car dashboards, and industrial equipment.
  • Power-efficient design, consuming energy only for active pixels.
Faqs:
  • What is the resolution of the 0.69-inch OLED screen?
    The 0.69-inch OLED screen has a resolution of 96x16 pixels, providing clear and detailed visuals.
  • What is the operating temperature range for this display module?
    This display module operates efficiently within a temperature range of -40°C to 85°C, making it suitable for various environments.
  • What type of interface does the ESHX9616TSWCG02 module use?
    The ESHX9616TSWCG02 module features a 14-pin IIC interface, ensuring easy connectivity and integration with your devices.
